Model: LDF8764ST
Front Controls
Model: LDF8764ST
LG top control dishwasher features hidden SmoothTouch™ controls with LED display, TrueSteam®, EasyRack™ Plus and can accommodate up to 15 place settings.
| GENERAL | |
| Type | Built-In |
| Color | Stainless Steel |
| Manufacturer Color | Stainless Steel |
| Place Settings | 15 |
| Tub Material | Stainless Steel |
| Silence Rating | 44 dB |
| CYCLE INFORMATION | |
| Number of Cycles | 6 |
| Wash Cycles | • Steam (Auto, Heavy, Delicate, Dual Control) • Normal • Quick and Dry • Heavy • Delicate • Dual Control |
| Options | • Sanitary Rinse Option • Extra Rinse Option |
| FEATURES | |
| Technologies | • EasyRack™ Plus System • SignaLight™ Cycle Indicator Light • Hidden SmoothTouch™ Controls with LED Display • TrueSteam™ • LoDecibel™ Quiet Operation • Slim Direct Drive Motor • SenseClean™ Wash System |
| Delay Start Information | Up to 19 Hours |
| Delay Start | Yes |
| Control Lock | Yes |
| Silverware Basket | Yes |
| Additional Information | • 3-in-1 Detachable Baskets • Stemware Holders • Racks and Tines Nylon Coated with Rounded Tips • Time Remaining Indicator • Rinse-Aid Indicator • SignaLight™ Cycle Indicator Lights 2: Operating, Clean • Overflow Detector • 120°F Inlet Water Capability • 3-Stage Filtration System • Delay Start Up To 19 Hours • 5 Multi-Level Water Direction • Hybrid Condensing Drying System • Dual Spray Intensity Feature • Variable Spray Intensities EasyRack™ Plus System: • Upper Rack Color-Coded Foldable Tines • Lower Rack Color-Coded Foldable Tines • Height Adjustable Upper Rack |
| ELECTRICAL INFORMATION | |
| Information | • 120 V • 60 Hz • 15 A |
| CERTIFICATIONS AND APPROVALS | |
| Energy Star Certified | Yes |
| DIMENSIONS | |
| Class Width | 24" |
| Width | 23.75 inch(es) / 60.33 cm |
| Height (Min.) | 33.5 inch(es) / 85.09 cm |
| Depth (Without Handle) | 24.63 inch(es) / 62.55 cm |
| Weight | 109.35 lb(s) / 49.60 kg |
| Additional Dimensions | Required Clearances (WxHxD): 24" x 33 1/2" x 24" |
| SHIPPING DIMENSIONS | |
| Width | 27.2 inch(es) / 69.08 cm |
| Height | 38.64 inch(es) / 98.15 cm |
| Depth | 29.6 inch(es) / 75.18 cm |
| Weight | 116.4 lb(s) / 52.80 kg |
| WARRANTY | |
| Warranty | • 1 Year Labor • 2 Year Parts • 5 Years on Control Board and Rack Parts • 10 Years Direct Drive Motor • Lifetime on the Stainless Steel Tub and Door Liner |
| UPC | |
| UPC# | 048231014380 |
